WALDRICH - SIEGEN ROLL GRINDING MACHINE-WS III 600

Used Roll Grinding Machine

Make:  WALDRICH-SIEGEN

Type:  WS III 600

Technical Data:

Max. grinding length:  4,300 mm

Max. grinding diameter:  800 mm

Dimension:  700 mm x 70 mm x 305 mm

Max. work piece: 10 tons

Grinding spindle speed: 650 - 1,300 U/min

Spindle head speed:  7 - 70 U/min

Grinding support:  60 - 3,000 U/min

Power grinding diameter:  25 PS

Power spindle head:  10 PS

Power gear of grinding diameter: 0.75 PS

Additional feature: with bombiere
