UNION - TABLE TYPE BORING AND MILLING MACHINE- BFK 110/6

Table Type Boring and Milling Machine
Make : Union
Model : BFK 110/6
Control: DIGITAL HEIDENHAIN TNC 151
Country of origin: Germany

Technical details:
Spindle diameter 110 mm
x-travel 2000 mm
y-travel 1250/1600 mm
z-travel 630 mm
Table dimenssions 1250 x 1600 mm
Tool taper ISA 50 / ISA 60
Table load 8000 kg
Speeds: 5-1400 U/min

Total power requirement 51 kW
weight of the machine ca. 22 ton
